LWG250 MMA 230A Gasoline Welding Generator With 5.0mm Electrode

Name: LWG250 MMA 230A Gasoline Welding Generator With 50mm Electrode
Brand: Lianwai
Price: 1 USD

Brand Name : Lianwai

Model Number : LWG250

Certification : CE

Place of Origin : China

MOQ : 5 SETS

Supply Ability : 1060 SETS

Delivery Time : 20 work days

Packaging Details : Carton

Welding current : 60-230A

Welding process : MMA

Duty cycle : 60%/220A/28.8V

Auxiliary power output : AC 3kW / 220V / 50Hz

Net weight : 72kg

Dimension : 710*560*650mm

Fuel : Gasoline

Protection/Insulation class : IP23

Contact Now

LWG250 230A Gasoline Welding Generator

Introduction

LWG250C is an industrial portable gasoline welding generator, which can output 230A welding current and 220V/50Hz single-phase 3KVA auxiliary AC power. Due to its small size, light weight, convenient movement and self-generation, it is ideal for welding in places without power supply and field construction operations.

Characteristics

1. IF power generation technology,
2. Welding current and thrust current are steplessly adjustable.
4. Beside MMA welding, it also has TIG function (scratch arc ignition type).
5.Auxiliary output: Single-phase, AC 3kW/220V/50Hz

Application

1. Maintenance of oil/gas/water pipeline welding,
2. Maintenance and repair of highway guardrails and power facilities,
3. Repair of fences and agricultural equipment in pastures and farms,
4. Supply power to small electric tools in the field without power supply: angle grinder, sander, electric drill, water pump, lighting equipment, etc.
5. Welding of stainless steel and carbon steel materials
6. Emergency power supply

Main specification sheet

Product Model		LWG250
Welding	No-load voltage(V0)	65-70
	Current range(A)	40-230
	Duty cycle(x)	60%/220A/28.8V
	Electrode diameter	￠2.5-￠5.0mm
Generating	Rated output single-phase 3kW/220V/50Hz
Engine	Brand	Senci
	Engine power	9.8kW/3600rpm
	Starting	Recoil
	Lubricant alarm system	Yes
	Emission(cc)	460
	Fuel capacity(L)	15
	Lubricant capacity(L)	1.1
	Fuel consumption(g/k.h)	400
Whole set	Insulation Class	H level 180℃
	Net weight(kg)	72Kg
	Overall Dimensions(L×W×H)	710560650mm

LWG250 MMA 230A Gasoline Welding Generator With 5.0mm Electrode
